Pass & Seymour Fuse Cutout
P & S Cutout #1

Marking:

(Recess-embossed on front)
30A
No P&S 1391/2
2500V

(Recess-embossed on back)

P391
MADE IN USA

Color:
Chocolate brown
Dimensions:
5-1/4 inches wide (13 centimeters)
5-1/4 inches tall (13 centimeters)

P & S Cutout #2

Marking:

(Recess-embossed on front)
P & S
No. 139 1/2
PATENTED
30 AMP 25000 VOLTS
Colors:
Dark Chocolate
Unglazed
Dimensions:
4-7/8 inches wide (12 centimeters)
5-1/4 inches tall (13 centimeters)
Notes:
There is an extra knob on the back of the glazed cutout that is not on the unglazed one.  This allows the glazed cutout to have three points of contact in the back: two where the bolts go through and one where the knob touches.
P & S. Cutout #3

Marking:

(Recess-embossed on front)
30A
P & S.
???
Color:
Dark chocolate
Dimensions:
5-5/8 inches wide (14.5 centimeters)
5 inches tall (12.5 centimeters)
8-1/4 inches tall with stick (21 centimeters)
Notes:
The stick on this one must be twisted counter-clockwise to remove it.

The top is coated with fine sand.



P & S Cutout #4

Marking:

P & S
30 AMP 2500 VOLTS

Color:

Dark Chocolate

Notes:

Thanks to Bob Scafe for the picture.





Cutout #5

Marking:

(Vertically marked) PAT JAN 10 1899
(Horizontally marked) P & S

Color: Unglazed

Thanks to Bob Scafe for the picture.
